Short Specs:-

• Monitors: Phase loss, Phase unbalance, Phase sequence, Overload trip current, Under / Over current in 3Ø motors.
• Accuracy : 5% of set value.
• 2 C/O output relay.
• Auto / Remote test available.
• MPCT range : 10A - 80A Earth Fault Current Measurement with EFCT : 1A to 160A Aux supply : 90 - 270V AC / DC
